Siemens 6ES7314-1AE04-0AB0 SIMATIC S7-300 CPU314 PLC Controller
Model: Siemens 6ES7314-1AE04-0AB0 SIMATIC S7-300 CPU314 PLC Controller
Parameter Specification Br…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
| Parameter | Specification |
|---|---|
| Brand | Siemens |
| Part Number | 6ES7314-1AE04-0AB0 |
| Model | CPU 314 (S7-300 Series) |
| Rated Supply Voltage | 24VDC (20.4~28.8VDC) |
| Rated Input Current | 1000mA |
| Max Inrush Current | 8A |
| Max Power Consumption | 8W |
| Integrated Work Memory | 24KB |
| Expandable Load Memory | Max 4MB Flash EPROM |
| Max Integrated RAM | 40KB |
| Typical Bit Instruction Time | 0.3μs |
| Typical Float Calculation | 50μs |
| S7 Counter Quantity | 64 |
| S7 Timer Quantity | 128 |
| Max Digital I/O | 1024DI / 1024DO |
| Max Analog I/O | 256AI /128AO |
| Built-in Interface | MPI (Max 187.5kbit/s) |
| Max MPI Nodes | 32 |
| Max Expansion Racks | 3 expansion units |
| Programming Software | STEP7 V5.0 & above |
| Overall Size(W×H×D) | 80 ×125 ×130 mm |
| Net Weight | Approx. 530 g |
