Schneider Electric ATV71HC13N4 Altivar 71 Variable Speed Drive
Model: Schneider Electric ATV71HC13N4 Altivar 71 Variable Speed Drive
Parameter Specification Br…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
| Parameter | Specification |
|---|---|
| Brand | Schneider Electric |
| Model | ATV71HC13N4 |
| Product Series | Altivar 71 |
| Rated Power | 132 kW / 175 HP |
| Input Voltage | 380…480 V 3-phase AC |
| Voltage Tolerance | -15% ~ +10% |
| Input Frequency | 47.5…63 Hz |
| Nominal Output Current (380V) | 253 A |
| Nominal Output Current (460V) | 210 A |
| Output Frequency Range | 0.1…599 Hz |
| Switching Frequency | 1~16 kHz adjustable |
| Apparent Power | 166 kVA |
| Integrated EMC Filter | Yes |
| Cooling Type | Forced air cooling with heat sink |
| Control Mode | V/F, sensorless & closed-loop vector control |
| Communication | Modbus, CANopen (optional Profibus/DeviceNet) |
| Protection Class | IP20 |
| Operating Temperature | -10 … +50 °C |
| Dimensions (W×H×D) | 400 × 1030 × 310 mm |
| Net Weight | 110 kg |
| Max Motor Cable Length | 100m shielded / 200m unshielded |
| Certifications | CE, UL, CSA, C-Tick, DNV |
