Mitsubishi
NF225-CP Mitsubishi NF225-CP
Model: NF225-CP Mitsubishi NF225-CP
FA-MCCB: Moulded-Case Circ…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
FA-MCCB: Moulded-Case Circuit Breaker
| Series | WS-V SERIES – MCCB |
|---|---|
| Type | NF-S TYPE (STANDARD CLASS) |
| Rated Current (A) | 225 |
| Rated Voltage (V) | 690 |
| Current Type | AC/DC |
| Number of Poles | 3 |
| Breaking Capacity at 400V (kA) | 36/36 |
| Compliant with Standard(s) | EN 60947-2, IEC 60947-2 |
| Frame Size | 250 |
| Cycles without Rated Current | 25000 |
| Cycles with Rated Current | 10000 |
| Automatic Tripping Device | THERMAL-MAGNETIC |
Product Dimensions & Weight
| Width (mm) | 105 |
|---|---|
| Height (mm) | 165 |
| Depth (mm) | 92 |
| Weight (kg) | 1,6 |
Conformity
| CE | COMPLIANT |
|---|---|
| Shipping Approvals | NK, LR, ABS, GL |
| UKCA | COMPLIANT |
