| Display |
Display:
Brightness (cd/m2):
Contrast Ratio:
Color:
Resolution (WXH):
Back Light:
Back Light Life Time: |
7″ TFT Widescreen
500
500:1
65536
800×600
LED
>30 000 hr |
|
| Processor: |
32bit RISC CPU 400MHz |
| Enclosure: |
Plastic |
| Touch Panel |
| Touch Panel Type: |
4-wire resistive type |
|
| Memory |
Flash:
RAM (RAM): |
128MB
64MB |
|
| I/O ports |
SD Card Slot:
USB Host:
USB Client:
Ethernet Port:
COM Port:AudioOutput: |
Yes
USB 1.1 Port x 1
USB 2.0 Port x 1
10/100 Base-T
COM1(RS232 / RS485 2W/4W),
COM2(RS232),COM3(RS232/RS485 2W)
Yes |
|
| Power |
Input Power:
Power Consumption: |
24 ??20% Vdc
250mA@24Vdc |
|
| RTC: |
Built-in |
| Specification |
Panel Cutout (WXH):
Weight: |
192x138mm
Approx 0.6kg |
|
| Operation |
CE:
Atex
UL:
Voltage Resistance:
Isolation Resistance:
Vibration Endurance:
Protection Structure:Storage Temperature:
Operating Temperature:
Operation Humidity: |
CE Marked
Atex Zone 2/22 Category 3 G/D
cULus Listed
500 VAC (1 min)
Exceed 50M?? at 500 Vdc
10 to 25 Hz (X,Y,Z direction 2g 30 minutes
UL Type 4X (indoor use only) / NEMA4 /
IP65 front panel
-20~60??C (-4??~140??F)0??~50??C (32??~122??F)
10-90% RH (non-condense) |
|
