MCR-FL-C-UI-2UI-DCI Phoenix Contact Signal conditioner
Model: MCR-FL-C-UI-2UI-DCI Phoenix Contact Signal conditioner
Electrical isolation betwe…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
| Electrical isolation between input and output | yes |
| Limit frequency (3 dB) | 30 Hz |
| Maximum power dissipation for nominal condition | 15 mW |
| Test voltage, input/output/supply | 1.5 kV AC (50 Hz, 60 s) |
| Protective circuit | Transient protection |
| Step response (10-90%) | 12 ms |
| Maximum temperature coefficient | < 0.015 %/K |
| Temperature coefficient, typical | 0.0075 %/K |
| Maximum transmission error | ≤ 0.15 % (of final value) |
| Transmission error, typical | 0.05 % (of final value) |
| Supply | |
| Supply voltage range | 20 V DC … 30 V DC |
| Max. current consumption | < 25 mA |
