MCR-C-U/U-DC Phoenix Contact Signal conditioner
Model: MCR-C-U/U-DC Phoenix Contact Signal conditioner
MCR 3-way signal condition…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
MCR 3-way signal conditioner, for galvanic isolation of analog signals, input signal: 0?…?10?V / (+/-) 10?V, output signal: 0?…?10?V / (+/-)10?V. Replacement part: 2902042 MINI MCR-2-U-U.
Electrical isolation between input and output yes
Limit frequency (3 dB) 30 Hz
Maximum power dissipation for nominal condition 450 mW
Test voltage, input/output/supply 1.5 kV AC (50?Hz, 60?s)
Protective circuit Transient protection
Step response (10-90%) 11 ms
Maximum temperature coefficient < 0.015 %/K
Maximum transmission error ?? 0.2 % (of final value)
Transmission error, typical < 0.1 % (of final value)
