Lenze
Lenze MDSKSRS071-33 Synchronous Servo Motor
Model: Lenze MDSKSRS071-33 Synchronous Servo Motor
Parameter Specification Br…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
| Parameter | Specification |
|---|---|
| Brand | Lenze |
| Model | MDSKSRS071-33 |
| Motor Type | Synchronous Servo Motor |
| Rated Torque (MN) | 12.3 Nm |
| Peak Torque (Mmax) | 52.0 Nm |
| Rated Power (PN) | 4.6 kW |
| Rated Speed (nN) | 3600 r/min |
| Max Speed | 5000 r/min |
| Rated Current (IN) | 10.0 A |
| Supply Voltage | 3×400 V AC |
| Feedback | Resolver (RV03) |
| Insulation Class | Class H (Class F utilization) |
| Protection Rating | IP54 |
| Cooling | Self-ventilated (non-ventilated) |
| Temperature Sensor | KTY thermal sensor |
| Shaft Diameter | 19 mm (k6) |
| Mounting | B5 / B14 |
| Dimensions (L×W×H) | 329 × 160 × 130 mm |
| Weight | 13.0 kg |
| Operating Temp | -20 … +40 °C |
| Certifications | CE, EAC, cULus, RoHS |
