GE
IC697PWR711H GE Power Supply
Model: IC697PWR711H GE Power Supply
Technical specifications f…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
Technical specifications for IC697PWR711
| Brand | GE Fanuc |
|---|---|
| Series | 90-30 PLC |
| Part Number | IC697PWR711 |
| Nominal rated voltage | 120/240 VAC |
| Input Power | 160 watts maximum at full load |
| Product Type | Power Supply Module |
| Load Capacity | 100 Watts |
| No. of Outputs | Three (3) |
| Output Voltage | +5 VDC: 4.90 to 5.25 volts (5.07 volts nominal) +12 VDC: 11.75 to 12.6 volts ‘ -12 VDC: -12.6 to -11.75 volts |
| Input Voltage Range, AC | 90-132 VAC / 180-264 VAC |
| Input Frequency Range | 47-63 Hz |
| Input Half Cycle Peak Inrush | 55 amps (typical), 77 amps (maximum) |
| Overvoltage Limit | +5 VDC Output: 5.7 to 6.7 volts |
| Overcurrent limit | +5 VDC output: 26 amp, maximum +12 VDC output: 4 amp, maximum -12 VDC output: 2 amp, maximum |
| Holdup Time: | 21 milliseconds minimum |
| Type | Power module |
| AC Input | 90 to 264 VAC |
| Frequency | 47 to 63 Hz |
| DC Input | 100 to 150 VDC |
| Voltage regulation | 5, 12, and -12 VDC |
| Power Factor | > 0,93 |
| Output power | 100 Watts maximum (total for all 3 outputs) |
| Operating temmperature | 0-60 degrees Celsius |
