IC697BEM733D GE I/O Scanner Module
Model: IC697BEM733D GE I/O Scanner Module
Technical specifications f…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
Technical specifications for IC697BEM733
| Brand | GE Fanuc |
|---|---|
| Series | Series 90-70 |
| Manufacturer | Manufacturer |
| Product Description | Remote I/O scanner |
| Part Number | IC697BEM733 |
| Series | Series 90-70 |
| Slot width | Single slot |
| Description | Genius Remote I/O Scanner |
| Part Number | IC697BEM733 |
| Status LED indicators | Module OK; I/O Enabled; Bus B Active; |
| Application | GE fanuc IC66 Bus |
| Product Description | IC697BEM733 |
| No. of Ports | One 15-pin RS-422/485 compatible serial port; One (1) 9-pin IC66* Hand-held Monitor port; One IC66* Bus terminal |
| Operating Voltage | 5.0 Volts DC |
| Description | Genius Remote I/O Scanner |
| Supported Data Rates: | data rates are 153.6K baud extended Up to 20 fully-loaded drops, or up to 30 drops if not fully-loaded; 153.6K baud extended Up to 20 fully-loaded drops, or up to 30 drops if not fully-loaded and 76.8K baud Up to 10 fully-loaded drops, or up to 30 drops if not fully-loaded |
| Backplane Current | 1.3 Amps |
| Maximum no. of drop station | Up to 32 devices |
| No. of devices per bus | 32 devices at 153.6 Kbaud standard, 153.6 Kbaud extended, or 76.8 Kbaud. 16 devices at 38.4 Kbaud. Includes bus controller and Handheld Monitor |
| I/O Capacity | 1024 Discrete I/O or 64 Analog I/O |
| Transmission speed | 153.6 Kbaud standardard and extended; 76.8 Kbaud; 38.4 Kbaud |
| Bus Topology | Daisy-chained bus cable; single twisted pair plus shield or Twinax |
| Location | IC697 PLC rack |
| Terminating Resistor values | 75, 100, 120 or 150 Ohms |
| Maximum Bus Length | 7500 feet (2275 meters) at 38.4 Kbaud, 4500 feet (1365 meters) at 76.8 Kbaud, 3500 feet (1060 meters) at 153.6 Kbaud extended, 2000 feet 605 meters) at 153.6 Kbaud, standard |
| Connectors | RS-422/RS-485 Serial Port and a 9-Pin Hand Held Monitor Connector |
| Application | GE fanuc IC66 Bus |
| Bus termination | 75, 100, 120, or 150 ohm resistor at both ends of electrical bus cable. |
| LED Indicators | 3 LEDs |
| Backplane Current | 1.3 Amps |
| Location | IC697 PLC rack |
| Backplane current consumption: | 800mA at 5VDC |
| Average Weight | 2.0 Pounds |
| Connectors | RS-422/RS-485 Serial Port and a 9-Pin Hand Held Monitor Connector |
| Product Lifecyle: | Discontinued |
| LED Indicators | Module OK; I/O Enables; Bus Active |
| Current draw | 0.8 A |
