ERN1387204862S14-70 Heidenhain Remote Controls
Model: ERN1387204862S14-70 Heidenhain Remote Controls
Part Description Heidenhai…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
Part Description
Heidenhain ERN 1387 2048 62S14-70 K 0,00 .. 65B06 40 01 .. .. RA ~1Vpp 05 01
Incremental rotary encoder with integral bearing for mounting by stator coupling
Line count: 2048
Add. circular-scale track: 1 sine and 1 cosine signal/revolution
Output signal: ~1Vpp
Cutoff frequency (-3dB): 210.00 kHz
Power supply: 5V (+-5%)
Coupling version: expanding ring coupling for mating diameter 65mm
Shaft: taper shaft 1:10, functional diameter 9.25mm, back-off thread M10 and M6
Degree of protection: IP 40 (EN 60529)
Operating temperature: -40/+120 ??C
Electrical connection: plug connector, straight, double-row, 14-pin, with locking mechanism and walls
Pin configuration: D319274
Connecting direction: Cable outlet for axial and radial use
