CJ1W-DA041 Omron Analog Output Unit
Model: CJ1W-DA041 Omron Analog Output Unit
Manufacturers OMRON Produc…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
Manufacturers
OMRON
Product Description
- Product Type: Analog Output Unit
- Unit type: CJ series special I/O unit
- Isolation *1: Between I/O and controller signals: Photocoupler (No isolation between I/O signals.)
- External terminals: 18-point removable terminal block (M3 screws)
- Power consumption: 5 VDC, 140 mA maximum
- External power supply *2: 24 VDC (Inrush current: 20 A maximum, Pulse width: 1 ms minimum)
- External power supply *2: Max. 200 mA
- Output specifications
- Number of analog outputs: 4
- Output signal range*3: 1～5V/4～20mA, 0～5V, 0～10V, -10～10V
- Output impedance: maximum 0.5Ω (for voltage output)
- maximum. Output current (1 point): 12mA (voltage output)
- Maximum allowable load resistance: 600Ω (current output)
- Resolution: 4,000
- Setting data: 16-bit binary data
- Accuracy*4: 25°C Voltage output: ±0.3% of F.S., Current output: ±0.5% of F.S.
- Accuracy*4: 0°C to 55°C Voltage output: ±0.5% of F.S., Current output: ±0.8% of F.S.
- D/A conversion cycle*5: 1.0 ms per point”
- Dimensions (L×W×H ):8.5×3×9cm
- Weight:0.187Kg
- Country of origin: Japan
