Allen – Bradley 1794-IRT8 Ethernet/IP Input Module Specification Sheet
Model: Allen – Bradley 1794-IRT8 Ethernet/IP Input Module Specification Sheet
Data Category Specific Par…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
| Data Category | Specific Parameters |
|---|---|
| Product Model | 1794-IRT8 |
| Brand | Allen – Bradley |
| Product Type | Ethernet/IP Input Module |
| Product Series | 1794 Compact I/O |
| Input Type | Digital Input |
| Number of Inputs | 8 |
| Input Voltage Range | 19.2 – 30 V DC |
| Input Current per Point | Typically 4 mA |
| Isolation Voltage | 500 V AC (input – to – logic), 1500 V AC (input – to – ground) |
| Filter Time Constant | 0.05, 0.1, 0.2, 0.4, 0.8, 1.6, 3.2, 6.4 ms (programmable) |
| Response Time (On) | Typically 1.2 ms (max 3.2 ms) |
| Response Time (Off) | Typically 1.2 ms (max 3.2 ms) |
| Communication Interface | Ethernet/IP |
| Power Consumption | 2.5 W (typical) |
| Operating Temperature Range | 0 – 60°C |
| Storage Temperature Range | -40 – 85°C |
| Humidity Range | 5 – 95% non – condensing |
| Vibration Resistance | 10 – 500 Hz, 2 g peak (random), 10 g peak (sinusoidal) |
| Shock Resistance | 30 g peak, 11 ms duration |
| Enclosure Rating | IP20 |
| Mounting Type | DIN rail or panel mounting |
| Dimensions (W×H×D) | 36.8 mm×121.9 mm×101.6 mm |
| Weight | 0.2 kg |
| Standards Compliance | CE, cULus, UL, ATEX, IECEx, RoHS |
| Certifications | Class I, Div 2, Groups A, B, C, D; Class II, Div 2, Groups F, G; Class III |
