ABB
ABB ACS880-01-021A-5 Low Voltage Industrial AC Drive
Model: ABB ACS880-01-021A-5 Low Voltage Industrial AC Drive
Data Category Specific Par…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
| Data Category | Specific Parameters |
|---|---|
| Product Model | ACS880-01-021A-5 |
| Brand | ABB |
| Product Type | Low Voltage Industrial AC Drive (Single Drive) |
| Frame Size | R2 |
| Input Specifications | 3-phase; Voltage: 380-500 V; Frequency: 47.5-63 Hz |
| Output Power (IEC) | Normal (Pn): 11 kW; Light Overload (PLD): 11.0 kW; Heavy Duty (PHD): 7.5 kW |
| Output Power (UL) | Light Overload: 15 Hp; Heavy Duty: 10 Hp |
| Output Current | Normal (In): 21 A; Light Overload (ILD): 19 A; Heavy Duty (IHD): 14 A |
| Apparent Power Output | 18 kV·A |
| Efficiency Level | IE2; Compliant with IEC61800-9-2 |
| Protection Rating | IP21; NEMA Type 1 |
| Mounting Type | Wall-mounted (cabinet installation optional) |
| Dimensions (W×H×D) | 155 mm × 409 mm × 245 mm (depth derived from series consistency) |
| Net Weight | 8.4 kg (18.519 lb) |
| Package 1 Specifications | 1 carton, 256 mm × 304 mm × 245 mm (depth inferred) |
| Operating Temperature Rating | Maximum 40 °C |
| Max. Installation Altitude | 4000 m |
| Sound Level | 59 dB(A) |
| Communication Protocols | CAN, DeviceNet, EtherNet/IP, MODBUS, PROFIsafe, PROFIBUS, PROFINET IO |
| Interfaces | 1×USB, 1×RS-485, 4×other interfaces, 2×PC connection ports |
| Key Features | Built-in harmonic filter; optional brake chopper/EMC filter/I/O extension; functional safety |
| Country of Origin | Finland |
| WEEE Classification | Category 5 (Small Equipment, ≤50 cm external dimension) |
| Customs Tariff/HS Code | 85044086; 850440 |
| SCIP Number | 7d5305e8-a099-4d63-aca9-fce6e19228fb |
| Ordering Details | MOQ: 1 piece; Order multiple: 1 piece; Made to order: Yes; Quote only: No |
| Product ID | 3AUA0000090435 |
| EAN Code | 6438177557128 |
