B&R
8i64t400220.000-1 B&R Servo Controller
Model: 8i64t400220.000-1 B&R Servo Controller
Mains connection Mains inp…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
Mains connection
| Mains input voltage | 3x 380 VAC -15% to 500 VAC +10% |
| Frequency | 50 to 60 Hz ±5% |
| Apparent power (at 500 VAC) | 5.3 kVA |
| Max. assumed short-circuit current (Isc) (short-circuit current at connection point) |
5 kA |
| Inrush current | Max. 10 A |
| Mains current | |
| At 380 VAC | 8 A |
| At 500 VAC | 6.1 A |
| Power dissipation at nominal load and nominal clock frequency | 76 W |
| Integrated EMC filter | Yes |
Mechanical properties
| Dimensions | |
| Width | 140 mm |
| Height | 228 mm |
| Height without shield plate | 184 mm |
| Depth | 158 mm |
| Weight | 2.1 kg |
