6GK6000-8CG01-0AA0 Siemens Accessory

Interfaces
Number of electrical/optical connections / for network
components or terminal equipment / maximum
1
Number of electrical connections
● for network components or terminal equipment
/ maximum
1
Number of 10/100/1000 Mbit/s RJ45 ports 1
Type of electrical connection
● for network components or terminal equipment RJ45
Ambient conditions
Ambient temperature
● during operation 0 … 70 °C
● during storage -40 … +85 °C
● during transport -40 … +85 °C
Design, dimensions and weights
Design SFP Module
Width 13.7 mm
Height 11.9 mm
Depth 56.5 mm
Net weight 0.01 kg
Mounting type latched
Standards, specifications, approvals
Standard
● for safety / from CSA and UL UL 60950-1, CSA C22.2 No. 60950-7
● for emitted interference EN 61000-6-4 (Class A)
● for interference immunity EN 61000-6-2
Laser protection class Complies with 21 CFR chapter 1, subchapter J
Certificate of suitability EN 61000-6-2, EN 61000-6-10
● CE marking Yes
● C-Tick Yes
● KC approval No
● E1 approval No
