6ES7222-1HF22-0XA0 Siemens Spare Part

Digital outputs
Number of digital outputs 8; Relays
Short-circuit protection No
Limitation of inductive shutdown voltage to to be provided externally (see manual package “Setting up an S7-
200”)
Output current
?? for signal “1” rated value 2 A
?? for signal “1” permissible range for 0 to 55 ??C,
max.
2 A
?? for signal “0” residual current, max. 0 mA
Total current of the outputs (per group)
all mounting positions
?? up to 40 ??C, max. 8 A
?? Current per conductor/group, max. 8 A
horizontal installation
?? up to 55 ??C, max. 8 A
Relay outputs
?? Number of operating cycles, max. 10 000 000; mechanically 10 million, at rated load voltage 100,000
Switching capacity of contacts
?? with inductive load, max. 2 A
?? on lamp load, max. 200 W; 30 W with DC, 200 W with AC
?? with resistive load, max. 2 A
Cable length
?? shielded, max. 500 m
?? unshielded, max. 150 m
Potential separation
Potential separation digital outputs
?? Potential separation digital outputs Yes; Relays
?? between the channels, in groups of 4
Connection method
Plug-in I/O terminals Yes
Dimensions
Width 45 mm
Height 80 mm
Depth 62 mm
Weights
Weight, approx. 170 g
