6EP13343BA10 Siemens Power Supplies

Manufacturer : Siemens

Product No. : 6EP1334-3BA10

Product Type : SITOP PSU200M 24 V/10 A Stabilized Power Supply

Wide-range input : Yes

Overvoltage resistance : 1300 Vpeak, 1.3 ms

Mains buffering : at Vin = 120/230 V, typ. 150 ms at Vin = 400 V

Mains buffering at Iout rated, min. : 25 ms; at Vin = 120/230 V, typ. 150 ms at Vin = 400 V

Switch-on current limiting (+25 °C), max. : 35 A

Output : Controlled, isolated DC voltage

Rated voltage Vout DC : 24 V

Total tolerance, static ± : 3 %

Product feature of the enclosure housing for side-byside mounting : Yes

Installation : Snaps onto DIN rail EN 60715 35×7.5/15

Electrical accessories : Buffer module

MTBF at 40 °C : 1 055 408 h

Weight : 0.80 Kg
