| Surrounding air temperature, max |
60 °C |
| North American temperature code |
T4 |
| Operating temperature |
0 °C |
| Emissions |
IEC 61000-6-4 |
| ESD immunity |
6 kV contact discharges, 8 kV air discharges |
| EFT/B immunity |
±4 kV @ 5 kHz on power ports, ±3 kV @ 5 kHz on shielded output ports |
| Relative humidity |
5…95% noncondensing |
| Conducted RF immunity |
10V rms with 1 kHz sine-wave 80% AM from 150 kHz…80 MHz |
| Surge transient immunity |
±1 kV line-line (DM) and ±2 kV line-earth (CM) on power ports, ±2 kV line-earth (CM) on shielded output ports |
| Radiated RF immunity |
10 V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz, 10 V/m with 200 Hz 50% Pulse 100% AM @ 900 MHz, 10 V/m with 200 Hz 50% Pulse 100% AM @ 1890 MHz, 3 V/m with 1 kHz sine-wave 80% AM from 2000…2700 MHz |
| Nonoperating temperature |
-40 °C |
| Voltage variation |
10 ms interruption on MOD power port |
Allen-Bradley
