2094-BC04-M03-M Allen Bradley Integrated Axis Module
Model: 2094-BC04-M03-M Allen Bradley Integrated Axis Module
Technical specifications f…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
Technical specifications for 2094-BC04-M03-M
| Manufacturer | Rockwell Automation |
|---|---|
| Operating Temperature | 32-122 F (0-50 C) |
| Part Number/Catalog No. | 2094-BC04-M03-M |
| Brand | Allen-Bradley |
| Continuous power output to bus | 27.6kW |
| Continuous output current to bus | 41.5 A |
| AC input Voltage | 324…528V rms,three-phase (360…480V nom) |
| Control Voltage | 95…264V rmss, ingle-phase (110…240V rms nom) |
| Bus overvoltage | 825V DC |
| Bus undervoltage | 275V DC |
| Power Dissipation range | 94-255 Watts |
| Installation Clearance | 50.8 mm (2.0 in.) |
| Minimum Enclosure Depth | 272 mm (10.7 in.) |
| Control Input Fuse | FNQ-R-10 (10 A) or FNQ-R-7.5 (7.5 A) |
| Control Input Breaker | 1492-SPM2D060 or 1492-SPM1D150 |
| DC Bus Power Fuse | Bussmann Fuse : WJ-20A14F Mersen: DCT20-2; HSJ20 |
| Dimensions | 7.7 x 11.9 x 16.7 in (196 x 302 x 426 mm) |
| Weight | 21.0 lbs (9.53 kg) |
| Max Bus Capacitance | 8955 Microfarads |
| Power Module | Integrated Axis Module |
| Output Current | 30 Amperes |
| Voltage Rating | 460 Volt (AC) |
| Nom Drive Voltage | 360-480 Volts (3 Phase) |
| Wattage | 13 kWatts |
