1794-IP4 Allen Bradley PLC Flex I/O 1794
Model: 1794-IP4 Allen Bradley PLC Flex I/O 1794
Technical Specifications f…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
Technical Specifications for 1794-IP4
| Manufacturer | Rockwell Automation |
| ON state Voltage, nom: | 24VDC |
| Number of Inputs: | Four (4) |
| No. of input groups: | Two (2) |
| Minimum Pulse width: | 2?s |
| Input Frequency: | 100 kHz |
| Terminal base: | 1794-TB2, 1794-TB3, 1794-TB3S, 1794-TBN, and 1794-TBKD |
| ON state Voltage, min: | 6VDC |
| ON state Voltage, max. | 26.4VDC |
| Product Description: | Flex IO Pulse counter module |
| Enclosure | Open-type |
| Mounting: | DIN Rail |
| Wire Size: | Determined by installed terminal base |
| Operating Temperature: | 0 to 55 C (32 to 131 F) |
| Storage Temperature: | -40 to 85 C (-40 to 185 F) |
| Vibration: | 5g @ 10 to 500 Hz |
| Operating Shock: | 30 g |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1794-IP4 |
| Product Type | Flex I/O 4 Channel Pulse Counter Module |
| Inputs | 2 per Interface |
| Pulse Counter Interfaces | 4 |
| Input Current | 3mA @ 6V DC |
| Input ON Range | 6-26.4V DC |
| Input OFF Range | -26.4-3V DC max. |
| Enclosure Type Rating | None(open-style) |
| Flexbus Current | 5mA @ 5V DC |
| Isolation Voltage | 500V DC |
| Power Dissipation | 5W @ 26.4V DC max. |
| Thermal Dissipation | 17.1 BTU/hr. @ 26.4V DC max. |
| UPC | 10612598137814 |
| UPC | 10612598184269 |
