1769-WS Allen-Bradley Weight Scale Module
Model: 1769-WS Allen-Bradley Weight Scale Module
Technical specifications f…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
Technical specifications for 1769-WS
| Brand | Allen-Bradley / Rockwell Automation |
|---|---|
| Series | CompactLogix |
| Part Number | 1769-WS |
| Product Type | Weigh Scale Module |
| Power | Provided from the backplane of the rack: +5Vdc |
| Backplane Current | < 0.5 Amps at 5V DC |
| Inputs | Signal, -0.3mV through +15.3 mV and Sense, +5Vdc |
| Outputs | Excitation 5V DC |
| Common Mode Rejection | 100dB at or below 60 Hz (minimum) |
| Resolution | Internal, 1:8,388,608 |
| Vibration Frequency Rejection | 0.25 Hz and above in 5 selectable steps |
| Weight | 0.6 lb (0.27 kg |
| Operating Temperature | 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) |
| Storage Temperature | -40 to 65 degrees Celsius (-40 to 185 degrees Fahrenheit) |
| Humidity | 5 to 95% (non-condensing |
| Weighing Modes | Net, Gross, Rate-of-change |
| Calibration | Electronic (C2) and Traditional (test weights) |
| Conversion Rate | 100 updates per second |
| Standards | UL/CUL, CE and Class I, Div 2, Group A, B, C & D |
| Indicators | âOKâ Module Status, bi-color LED, âScale 1â Functional Data, bi-color LED and âScale 2â Functional Data, bi-color LED |
