1769-IF4 Allen-Bradley Analog Input Module

Manufacturer Rockwell Automation
Brand Allen-Bradley
Part Number/Catalog No. 1769-IF4
Product Line CompactLogix
Module Type 4 Channel Analog Input Module
Product Type Analog Input Module
Input Type Analog Input
Compatible Controllers: MicroLogix 1500; 1769 CompactLogix
No. of Inputs: 4 Differential and Single Ended Inputs
Communication Cable 4 Point
Shipping Weight 2 lbs.
Power Supply Distance rating: 8
Shipping Dimensions 8X8X5 in.
Input current range: 0-21 mA
Current signal normal ranges: 0-20mA; 4-20 mA
Series A and B
Converter Type Delta Sigma
Current signal full range: 0-21 mA; 3.2 – 21 mA.
Backplane Current 1.4 Amps at 24 Volts
Input voltage range: 0-10.5VDC
Power Consumption 33.6 Watts
Voltage signal normal ranges: ±10V DC, 0 …10V DC, 0…5V DC, 1…5V DC
External Power Switch 24 VDC
Voltage signal full range: ±10.5V DC, -0.5…10.5V DC, -0.5…5.25V DC, 0.5…5.25V DC
Power Dissipation 7.5 Watts
Resolution: 14 bits (unipolar) 14 bits plus sign (bipolar)
UPC 10662468992937
Rated working voltage: 30VAC; 30VDC
