1762-IQ8 Allen-Bradley VDC Sink/Source Input Module
Model: 1762-IQ8 Allen-Bradley VDC Sink/Source Input Module
Technical specifications f…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
Technical specifications for 1762-IQ8
| Manufacturer | Rockwell Automation |
|---|---|
| Module Type | Discrete input module |
| Series | MicroLogix |
| Part Number/Catalog No. | 1762-IQ8 |
| Brand | Allen-Bradley |
| No. of Inputs | Eight (8) channels |
| No. of groups | One (1) isolated groups |
| Channels per group: | Eight (8) |
| Nominal input voltage | 24VDC |
| Input voltage range | 10-30 VDC |
| ON-state Current, min. | 2.0 mA min. at 10VDC; 8.0 mA nominal at 24VDC; 12.0 mA max. at 30VDC |
| Off-state Current, max. | 1.5 mA |
| Signal Delay, ON transition | 8 ms |
| Backplane Current, 5.1VDC | 50 mA |
| Backplane Current, 24VDC | 0 mA |
| Isolation rating | Verified by one of the following dielectric tests: 1200V ac for 1 sec. or 1697V dc for 1 sec. 75V dc working voltage (IEC Class 2 reinforced insulation) |
| Input Power | 24 Volts DC |
| Inputs | (8) Sink and Source |
| Operating Voltage Range | 10 to 30 Volts DC |
| Heat Dissipation | 3.7 Watts |
| UPC | 10612598207203 |
