1762-IQ32T Allen-Bradley DC Input Module
Model: 1762-IQ32T Allen-Bradley DC Input Module
Technical specifications f…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
Technical specifications for 1762-IQ32T
| Manufacturer | Rockwell Automation |
|---|---|
| Module Type | High-density Discrete input module |
| Series | MicroLogix |
| Part Number/Catalog No. | 1762-IQ32T |
| Brand | Allen-Bradley |
| No. of Inputs | Thirty-Two (32) channels |
| No. of groups | Four (4) isolated groups |
| Channels per group: | Eight (8) |
| Compatible controllers: | MicroLogix 1100, 1200 and 1500 |
| Nominal input voltage | 24VDC |
| Input voltage range | 10-30 VDC |
| ON-state Current, min. | 1.6 mA @ 10V DC; 2 mA @ 15V DC |
| Signal Delay, ON transition | 8 ms |
| Backplane Current, 5.1VDC | 170 mA |
| Backplane Current, 24VDC | 0 mA |
| Isolation rating | Verified by one of the following dielectric tests: 1,200V AC for 2 s or 1,697V DC for 2 s 75V DC working voltage (IEC Class 2 reinforced insulation) |
| Input Power | 24 Volts DC (Sink/Source) |
| Operating Voltage Range | 10 to 26.4 Volts DC |
| Inputs | 32 |
| Mounting Type | DIN Rail |
| Bus Current Draw | 0-170 milliamps |
| Signal Delay | 8 milliseconds |
| Heat Dissipation | 5.4 to 6.8 Watts |
| UPC | 10612598849908 |
