1761-L20AWA-5A Allen Bradley Control Unit
Model: 1761-L20AWA-5A Allen Bradley Control Unit
Technical specifications f…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
Technical specifications for 1761-L20AWA-5A
| Manufacturer | Rockwell Automation |
|---|---|
| Brand | Allen-Bradley |
| Controller | MicroLogix 1000 |
| Part Number/Catalog No. | 1761-L20AWA-5A |
| I/O Count | 20 points |
| Input Type | 120V ac |
| Memory: | 1 K EEPROM composed of approximately 737 instruction words and 437 data words. |
| Communication port: | RS232 |
| Analog Circuits | 4 Inputs, 1 Output |
| Protocol: | DF1 |
| Safety Feature | Master Control Relay |
| Product Type | Programmable Logic Controller (PLC) |
| Digital Outputs | 8 Contact Outputs |
| No. of Discrete Inputs | Twelve (12) |
| Dimensions (L x D x H) | 7.87 x 2.87 x 3.15 inces |
| Input Voltage Type | 120 Volts AC |
| Voltage Range | 79-132 Volts AC |
| Output Type | Eight (8) Relay |
| UPC | 10662072766498 |
| Discrete Output Voltage | 24-125 VDC; 0-240VAC |
| Analog Input | Four (4) |
| Product Lifecycle Status* | Discontinued/Obsolete |
| Analog Input Signals | Voltage -10.5 to +10.5V dc – 1LSB; Current 21 to +21 mA – 1LSB |
| Data Type | 16-bit signed integer |
| Input Coding | -32,768 to +32,767 |
| Analog Output | One (1) |
| Power Supply | 120/240 Volts AC |
| Analog Output signal | 0 to 10V dc -1LSB; 4 to 20 mA – 1LSB |
