1756-OF8H Allen-Bradley Module
Model: 1756-OF8H Allen-Bradley Module
Manufacturer Rockwell Auto…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1756-OF8H |
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Series | ControlLogix |
| Series | ControlLogix |
| Module Type | Hart Analog Output Module |
| Module Type | Analog output Module with HART capability |
| Outputs | 8 Differential |
| No. of Inputs | Eight (8) output channels |
| Input Current Range | 0-20 or 4-20 milliamps |
| Output signal | Current: 0-20 mA; 4-20 mA Voltage: +/-10VDC |
| Isolation Voltage | 50 Volts Continuous |
| Resolution | 15-16 Bits |
| Overvoltage Protection | 24 Volts DC |
| Accuracy | Voltage: 0.1% of range Current: 0.5% of range |
| Enclosure | Open |
| Removeable Terminal Blocks | 1756-TBNH, 1756-TBSH |
| Data Format: | Integer mode (left justified, 2 s complement) IEEE 32-bit floating point |
| Input conversion method | Successive approximation |
| Output conversion method | R-Ladder DAC, monotonicity with no missing codes |
| Removable terminal block | 1756-TBCH; 1756-TBSH |
| Removeable Terminal Block(s) | 1756-TBNH, 1756-TBSH |
| Current Draw | 230 mA @ 5.1 VDC and 230 mA @ 24 VDC |
| Isolation Voltage | 50 Volts Continuous |
| Enclosure | None |
| Open circuit detection time | Current output only (output must be set to < 0.1 mA) |
| UPC | 10612598345486 |
| Overvoltage protection, max | +/- 24 VDC |
