Allen-Bradley
150-C25NBR Allen-Bradley Smart Motor Controller
Model: 150-C25NBR Allen-Bradley Smart Motor Controller
Manufacturers Allen-Bradle…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
Manufacturers
Allen-Bradley
Model(s)
Allen-Bradley driver
Product Description
| Degree of protection (IP) | IP2X |
| Weight | 0.86 kg |
| Shock | Operational: 15 G |
| Width | 44.8 mm (1.76 inch) |
| Depth | 110 mm (4.33 inch) |
| Height | 139.7 mm (5.5 inch) |
| Cable size | 2.5…25 mm² (14…4 AWG) for line power terminals |
| Vibration | Operational: 1.0 G peak, 0.15 mm (0.006 inch) displacement |
| Make | TB-97, -98 (OVLD/Fault): 432VA for auxiliary contacts |
| Break | TB-97, -98 (OVLD/Fault): 72VA for auxiliary contacts |
| Tightening torque | 2.3…3.4 Nm (30 lb.inch) for line power terminals, 4.0 Nm (35 lb.inch) if 25 mm² (4 AWG) wire in top terminal for line power terminal |
| Internal bypass | Yes |
| Function | Single direction |
| Selectable kick start – 450% FLA | 0, 0.5, 1.0, or 1.5 s |
| Selectable initial torque | 15%, 25%, 35%, and 65% of locked rotor torque |
| Selectable soft stop | Off, 100%, 200%, or 300% of the start time setting when wired |
