1478130000 Weidm??ller Power Supplies
Model: 1478130000 Weidm??ller Power Supplies
Version Power supply, swit…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
| Version | Power supply, switch-mode power supply unit, 24 V |
| Order No. | 1478130000 |
| Type | PRO MAX 240W 24V 10A |
| GTIN (EAN) | 4050118286052 |
| Qty. | 1 ?items |
| Depth | 125 ?mm |
| Depth (inches) | 4.921 ?inch |
| Height | 130 ?mm |
| Height (inches) | 5.118 ?inch |
| Width | 60 ?mm |
| Width (inches) | 2.362 ?inch |
| Net weight | 1,050 ?g |
Temperatures
| Storage temperature | -40 ??C…85 ??C |
| Operating temperature | -25 ??C…70 ??C |
| Humidity at operating temperature | 5…95 %, no condensation |
input
| AC input voltage range | 85??277 V AC |
| Connection system | Screw connection |
| Current consumption in relation to the input voltage |
|
| DC input voltage range | 80…370 V DC |
| Frequency range AC | 45??65 Hz |
| Input fuse (internal) | Yes |
| Inrush current | max. 15 A |
| Nominal power consumption | 262.3 ?VA |
| Power factor |
|
| Rated input voltage | 100…240 V AC |
| Recommended back-up fuse | 10 A, Char. B circuit breaker 6…8 A, char. C circuit breaker |
| Surge protection | Varistor |
output
| Connection system | Screw connection |
| Continuous output current @ UNominal | 12 A @ 45??C, 7,5 A @ 70??C |
| Nominal output current for Unom | 10 A @ 60 ??C |
| Output power | 240 ?W |
| Output voltage, max. | 29.5 ?V |
| Output voltage, min. | 22.5 ?V |
| Output voltage, note | (adjustable via potentiometer) |
| Parallel connection option | yes, max. 5 |
| Protection against inverse voltage | Yes |
| Rated output voltage | 24 V DC ?? 1 % |
| Residual ripple, breaking spikes | <50 mVss @ UNenn, Full Load |
General data
| AC failure bridging time @ Inom | min. 20 ms |
| Current limiting | > 120% IN |
| Degree of efficiency | 91.5% |
| Derating | > 60??C / 75% @ 70??C |
| Earth leakage current, max. | 3.5 ?mA |
| Housing version | Metal, corrosion resistant |
| Mounting position, installation notice | Horizontal on TS35 mounting rail. 50 mm of clearance at top & bottom for air circ. Can mount side by side with no space in between. |
| MTBF |
|
| Power loss, idling | 2.4 ?W |
| Power loss, nominal load | 22.3 ?W |
| Protection against reverse voltages from the load | 30??35 V DC |
| Protection degree | IP20 |
| Short-circuit protection | Yes |
| Start-up | ?? -40 ??C |
| Status indication | LED red/green and relay (??21.6 V DC LED green, relay on/ ??20.6 LED red, relay off) |
| Surge voltage category | III |
