140CPS52400 Modicon Power Supply module
Model: 140CPS52400 Modicon Power Supply module
Range of Product Modicon Q…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
| Range of Product | Modicon Quantum automation platform |
|---|---|
| Product or Component Type | Power supply module |
| Power supply type | Redundant |
| Input voltage | 125 V 100…150 V) DC |
|---|---|
| Input current | 500 mA 125 V |
| Inrush current | 28 A 125 V |
| Maximum input power interruption | 1 ms |
| Associated fuse rating | 2 A, slow-blow |
| Output voltage | 5.1 V DC |
| Power supply output current | 8 A redundant |
| Output overvoltage protection | Internal |
| Output overload protection | Internal |
| Power dissipation | 6 + (1.5 x Iout) where Iout is in A |
| Local signalling | For power (PWR OK) 1 LED (green) |
| Marking | CE |
| module format | Standard |
| Net Weight | 1.43 lb(US) (0.65 kg) |
| Standards | CSA C22.2 No 142 UL 508 |
|---|---|
| Product Certifications | FM Class 1 Division 2 cUL |
| Resistance to electrostatic discharge | 4 kV contact IEC 801-2 8 kV on air IEC 801-2 |
| Resistance to electromagnetic fields | 9.14 V/m (10 V/m) 80??2000 MHz IEC 801-3 |
| Ambient Air Temperature for Operation | 32??140 ??F (0??60 ??C) |
| Ambient Air Temperature for Storage | -40??185 ??F (-40??85 ??C) |
| Relative Humidity | 95 % without condensation |
| Operating altitude | <= 16404.2 ft (5000 m) |
| Category | US1PC2118155 |
|---|---|
| Discount Schedule | PC21 |
| GTIN | 3595861137127 |
| Returnability | No |
| Country of origin | CN |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 1.90 in (4.83 cm) |
| Package 1 Width | 6.50 in (16.51 cm) |
| Package 1 Length | 12.40 in (31.5 cm) |
| Package 1 Weight | 2.01 lb(US) (0.91 kg) |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 7 |
| Package 2 Height | 11.81 in (30 cm) |
| Package 2 Width | 11.81 in (30 cm) |
| Package 2 Length | 15.75 in (40 cm) |
| Package 2 Weight | 14.99 lb(US) (6.8 kg) |
| Warranty | 18 months |
|---|
