140CPS22400 Schneider Electric Power Supplies
Model: 140CPS22400 Schneider Electric Power Supplies
Main Range of Product Modi…
- Genuine products, direct from the factory
- Technical selection and commissioning support
- Bulk purchasing and customization available
Specifications & Service
| MOQ | 1 PCS |
|---|---|
| Warranty | 1 year |
| Delivery Time | 3-5 days |
| Shipping | FedEx/DHL/UPS/TNT |
| Payment | TT/Western Union |
Product Details
| Range of Product | Modicon Quantum automation platform |
|---|---|
| Product or Component Type | Power supply module |
| Power supply type | Redundant |
| Input voltage | 24 V 20…30 V) DC |
|---|---|
| Input current | 3800 mA |
| Inrush current | 14 A 20 V 25 A 24 V |
| Maximum input power interruption | 100 ms 1 ms 20 V |
| Associated fuse rating | 5 A, slow-blow |
| Output voltage | 5.1 V DC |
| Power supply output current | 8 A redundant |
| Output overvoltage protection | Internal |
| Output overload protection | 2.3 x maximum rated input voltage for 1.3 ms |
| Power dissipation | 6 + (1.8 x Iout) where Iout is in A |
|---|---|
| Alarm output | 1 NC 6 A 220 V power supply fault |
| Local signalling | for power (PWR OK) 1 LED (green) |
| marking | CE |
| Module format | Standard |
| Net Weight | 1.43 lb(US) (0.65 kg) |
